Abrazadera WQT·G4 DIN 3015-3 — ø10 mm
Tornillo hexagonal exterior + cuerpo doble + tapa + tuerca de carril · Tuerca de carril
| N.º de producto | WQT*G4-110 |
| Norma | DIN 3015-3 |
| Serie | WQT·G4 |
| Ø exterior | ø10 mm |
| Grupo de tamaño | T1 |
| Tornillo | M6×35 · Outer hex |
| Montaje | Tuerca de carril |
| Cuerpo L1 × H | 36 × 27 mm |
| Tapa | Incluida |
| Plazo de entrega | A consultar |
| Material del cuerpo | Carbon steel, zinc-plated |
| Placa base | Carbon steel, zinc-plated |
| Material del tornillo | Carbon steel, zinc-plated |
| Apto para | Tubos ✓ · Mangueras — · Cables — |
| Amortiguación | Ninguna (abrazadera de acero rígida) |
| País de origen | China |
Technical context for this SKU
- DIN 3015-3 WQT·G4, pipe OD ø10 mm, size group T1.
- Clamp body L1 x H is 36 x 27 mm; bolt size is M6×35.
- WQT*G4-110 uses a tuerca de carril configuration; it fits mounting rails where position adjustment is useful for compact pipe layouts.
- Standard material is Carbon steel, zinc-plated; stainless or surface-treatment options can be reviewed for corrosive or marine service.
Suitable applicationsCompact pipe runs, machine interiors and layouts where installation space is limited.
Selection checksConfirm pipe OD ø10 mm, group T1, mounting method, load direction and nearby bends or valves.
Environment noteFor outdoor, marine or corrosive service, review surface treatment or stainless alternatives.
Recommended RFQ details
- Part number or series: WQT*G4-110 / WQT·G4
- Pipe OD, quantity and whether cover plates, bases, rails or stacking parts are needed
- Fluid, pressure, temperature, vibration source and installation environment
- Material, surface treatment, certificate needs and delivery target
